Specifications

Fuzz Fields Quick Start Guide

    • Input & Output TS or TRS 6.35mm

    • When a TRS plug is used, the Ring connection bypasses directly to the output jack, while the fuzz effect is applied to the Tip channel of the stereo TRS jack

    • Ultra robust footswitch made in EU

    • True bypass using relay+microcontroller+firmware

    • Dual user friendly operation per footswitch

      1. Right Footswitch: Toggles device on/off and activates phase shifter mode (hold for turning on/off phase shifter)

      2. Left Footswitch: Activates internal Oscillator and Gravity Mode (quick double tap for cycling between different modes)

    • Footswitch Memory: Saves the last footswitch status in internal memory for consistent device state recall

    • Mutes the Oscillator when the device is off, preventing high-frequency component leakage into the audio signal chain

    • EXP :
      TRS 6.35 mm
      Tip: Wiper
      Ring: +7.5VDC
      Sleeve: Ground
      or
      CV :
      TS 6.35 mm
      Tip: CV Singal
      Ring: Safely Grounded
      Sleeve: Ground

    • ENV OUT :
      TS 3.5mm
      Tip: CV (0-5V)
      Sleeve: Ground
      Diode Protected

    • CV IN :
      TS 3.5mm
      Tip: CV signals
      Sleeve: Ground
      Diode Protected

    1. Smooth: Expression envelope timing

    2. +Sense: Sensitivity adjustment for low/high output instruments

    3. +Time: Short or Long envelope time

    4. Latch: Momentary or Latch function for the Left footswitch

    • Use a 9VDC, 2.1mm (tip-negative)

    • Current draw ~ 80mA

    • Does not run on batteries

    • when no power, constantly bypassed

    • 93x140x55mm (including the knobs)

    • 325gr weight
